Research area:

Triboelectric Energy harvester

Project: Development of Cost-effective Triboelectric Energy Harvester: Performance Enhancement and Systematic Experimental Study

Abstract: A comprehensive experimental study has been performed to develop the reliable cantilever structured TEH device prototypes and further performance enhancements by altering the surface and bulk profile of the PDMS polymer tribo-layer with the cost-effective fabrication process. A cost-effective experimental test set-up has been developed to test the vertical contact-separation mode triboelectric energy harvesting devices for the real-time measurements of input and output parameters with less than 2% uncertainty. A systematic experimental study of resistive load matching and extensive experimental parametric case study has been carried out to correlate the tapping frequency with force excreted by tapping and its effect on TEH performance for a low-frequency range (1Hz to 7Hz).

Fig. Different device prototypes, (a) cantilever design with PDMS layer on top electrode, (b) cantilever design with PDMS layer on the bottom electrode, (c) cantilever design with top electrode Cu attached to the cantilever realised with the insulator (Cardboard and Kapton film) and (d) schematic of self-powered LED system realised with TEH.

Fig. PDMS layer with surface roughness created by soft-lithography.

Fig. voltage output of TEH device

Fig. Self-powered LED system.

Fig. Instantaneous power w.r.t. load resistance.

Biosensor

Project: Non-Destructive Real-Time Glucose Quantification Using 5-Turn eandered Signal Coplanar Sensor Integrated with Circular PDMS Cavity

Abstract:

The experimental demonstration in the prospective application of the novel label-free microwave-based Meandered Signal Coplanar Sensor (MSCS), for the non-destructive quantification of the glucose in aqueous solution, has been presented. The sensor has been designed by embedding 5-turn meander inductor in the signal conductor of a 50_ coplanar waveguide (CPW) transmission line, where the sensing area is configured with Polydimethylsiloxane (PDMS). Precursory modelling of the CPW transmission line and the meander inductor have been executed in MATLAB and further optimization has been carried out in 3D CST Microwave Studio Suite 2017 simulator. The experimentally measured magnitude and peak frequency for S11 and S21, respectively, showed good sensitivity of 18.42 dB/g/ml, 265.72 MHz/g/ml, 36.51 dB/g/ml and 1050 MHz/g/ml, respectively. The regression analysis with high linearity of 0.921, 0.944, 0.762, and 0.839, respectively, validated the correlation of the glucose concentration with the magnitude and peak frequency of the S-parameters.

Project: Development of Glucose Biosensor Using Microwave Sensing Technology.

Abstract: My thesis includes design development, design optimization, simulation, and glucose analyzer fabrication using PCB based on microwave sensing technology. The measured result was compared with the simulated result. The measured result is published in the internationally reputed journal.

  • Design and Simulation Experience includes:
  • Design optimization using Microwave CST 2017 software
  • Simulation of optimized design using Microwave CST Studio software
  • Fabrication:
  • Fabricated device on the FR4 material.
  • Interdigital structure is made with the help of local industry.
  • Pouring cavity is made on device in lab.
  • SMA connectors is attached in the lab.
  • Testing of device:
  • Device was tested using vector network analyser in the lab with the different concentration of Glucose solution in the lab.

Project:

Abstract: A real-time label-free microwave diagnostic approach using Co-Planar Waveguide (CPW) design has been demonstrated for glucose detection. This mechanism has tremendous potential for the biomedical applications. Here, glucose biosensor is implemented with 50Ω CPW transmission line, where the centre localized 3mm diameter of CPW transmission line has been used for the sensing. Glucose sensor is implemented utilizing low cost multilayer PCB and polymer Poly-Di-Methyl-Siloxane (PDMS) fabrication technology. CPW transmission line is fabricated on FR4 microwave laminate board. To confine the Analyte Under Test (AUT) on the sensing area, PDMS polymer cavity is configured in the centre of CPW transmission line. The electromagnetic interaction with the varying dielectric constant of Glucose: DI water solution results shift in S11 parameter, which is closely observed to use as the source of sensing. CPW based glucose sensor is experimentally measured for S11 parameter using VNA, with varying glucose concentration range from 0 mg/ml (only DI water) to 4 mg/ml with the interval of 1 mg/ml. The measured results showed good sensitivity of 108.4 MHz/mg/ml and high accuracy with good linear regression coefficient of 0.9979.

Design of microwave devices using Machine learning

Project: Prediction of design parameters of Microstrip Transmission Line using Machine Learning techniques.

An artificial neural network (ANN)-based prediction model  has been demonstrated to analyse microstrip transmission line (MTL) for the characteristic impedance, Z0. The ANN predictionmodel will overcome the time and effort  required to design MTL using costly radio frequency (RF) software tools. The ANN  model has been developed using feed forward back propagation (F-F B-P) algorithm with three hidden layers and optimized by gradient descent (GD) optimizer. ANN model has been developed on the dataset built using analytical formulation. The training, validation and test error obtained for the model are 7.197×105, 6.189×105 and 0.66, respectively, demonstrating high accuracy.
